Premium Techanical Support Trading Est are Manufacturer, Exporter and Supplier of Stainless Steel Flanges. Premium Techanical Support Trading Est are Manufacturing Stainless Steel 347 Flanges of high quality raw materials. SS 347 flanges are precise in size, resistant to corrosion & non-reactive to chemicals including acids. Stainless Steel 347 Flanges are basically used for changing the route of liquid material.
Stainless Steel 347 Flanges Specifications
| Standards | : | ASTM, ASME Flanges, ANSI Flanges, DIN Flanges, EN Flanges, BS Flanges etc. |
| Designation | : | A 182 / A 240, SA 182 / SA 240 |
| Grade | : | Stainless steel 347 Flanges |
| Class | : | PN6, PN10, PN16, PN25, PN40, PN64. 150#, 300#, 600#, 900#, 1500#, 2500#. |
| Dimension | : | B16.5, BS4504, EN-1092, |
Stainless Steel 347 Flanges Equivalent Grades
| STANDARD | UNS | WERKSTOFF NR. |
| SS 347 | S34700 | 1.4550 |
Stainless Steel 347 Flanges Chemical Composition
| Grade | C | Mn | Si | P | S | Cr | Cb | Ni | Fe |
| SS 347 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 20.00 | 10xC – 1.10 | 9.00 - 13.00 | 62.74 min |
| SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 - 19.00 | 8xC – 1.10 | 9.0 -13.0 | 63.72 min |
Stainless Steel 347 Flanges Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1454 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Stainless Steel 347 Flanges Available Types
| Stainless Steel 347 Flanges | Steel 347 Flanges |
| Stainless Steel 347 Pipe Flanges | SS 347 Flanges |
| Stainless Steel 347 Welding Neck Flange | F347 Stainless Steel Forged Flanges |
| SS 347 Slip on Flange | Stainless Steel ASTM A182M 347 Plate Flanges |
| Stainless Steel 347 Blind Flange Distributor | ASME B16.5 SS 347 High Hub Blind Flange |
| SS 347 Socket Weld Flanges Manufacturer | Steel 347 Lap Joint Flanges |
| 347 Stainless Steel Threaded Flanges | Stainless Steel DIN 1.4550 RTJ Flange |
| Stainless Steel F347 ASME Flanges | 347 Stainless Steel ANSI Flanges |
| ASTM A182 Stainless Steel Reducing Flanges | 347 Stainless Steel Long Weld Neck Flanges |
| Stainless Steel UNS S34700 Orifice Flange | ANSI B16.5 SS 347 WNRF Flange Supplier |
| ASME SA182 SS 347 Spectacle Blind Flanges Stockist | 347 Stainless Steel Screwed Flanges |
| Wrought Austenitic Stainless Steel 347 SORF Flanges | 347 Stainless Steel BLRF Flanges Stockiest |
| SS 347 Ring Type Joint Flanges Exporter | ASTM A182M 347 SS DIN Flanges Dealer |
